Current model: SC1801PPV | Former model: SC1730PM
SC1801PPV Micro Diaphragm Vacuum Pump for Beauty Devices
SC1801PPV is a compact diaphragm vacuum air pump for controlled negative-pressure circuits in OEM beauty devices. The supplied product drawing lists DC 3V, 6V and 12V versions, airflow above 0.7L/min, vacuum performance around −32kPa and pump-level noise below 60dB at 30cm.
Medium: Air only
Former model: SC1730PM
Request a Sample and Vacuum-System ReviewCompact Vacuum Source for Beauty Equipment
SC1801PPV provides an air-only vacuum source for devices that use controlled suction, adsorption or pulsed negative pressure. The pump's maximum vacuum is not a recommended skin-contact setting. Finished equipment must regulate the user-side pressure with a pressure sensor, valve system and validated control logic.
- Compact L-shaped layout: Designed for space-constrained OEM assemblies.
- Three voltage options: DC 3.0V, 6.0V and 12.0V versions shown in the supplied drawing.
- Airflow above 0.7L/min: Supports fast evacuation in compact pneumatic circuits; final flow depends on vacuum load and line restriction.
- Vacuum around −32kPa: Pump-level capability that must be regulated for the final application.
- Noise below 60dB: Measured at 30cm under the supplied drawing condition.
- Intermittent endurance profile: 50,000 cycles at 10s ON, 2s OFF and 5s EXHAUST according to the supplied drawing.


Technical Specifications
| Current model | SC1801PPV |
|---|---|
| Former model | SC1730PM |
| Pump type | Micro diaphragm vacuum air pump |
| Rated voltage | DC 3.0V / 6.0V / 12.0V |
| Rated current | <500mA / <350mA / <200mA |
| Airflow | >0.7L/min |
| Vacuum | Approximately −32kPa |
| Noise | <60dB at 30cm |
| Medium | Air |
| Life test | 50,000 cycles; 10s ON / 2s OFF / 5s EXHAUST |
| Working environment | 0–50°C, 75% RH |
| Approximate pump-head section | 17.5±0.3mm × 17.5±0.3mm; use the approved 2D drawing for mechanical design |
Beauty-Device Integration Considerations
1. Regulate the User-Side Vacuum
The pump should be part of a closed-loop pneumatic system. Use a pressure sensor and valve or vent path to limit operating vacuum, detect a blocked nozzle and release suction promptly.
2. Keep Liquid Out of the Pump
The specified medium is air. Add a liquid trap, suitable filter and anti-backflow design when the device may encounter moisture, skin oil, cleaning fluid or condensate. Do not route liquid or cosmetic essence directly through the pump unless a separately approved wet-media version is provided.
3. Validate Noise and Vibration in the Final Housing
Pump-level noise is specified below 60dB at 30cm. Use elastomer mounts, flexible tubing and resonance control, then test the complete device in its actual operating modes.
4. Match the Duty Cycle
The supplied endurance profile is intermittent. Continuous operation, different pulse patterns or higher ambient temperatures require separate thermal and life validation.
Products Description

Skoocom implements a comprehensive quality management system and has successively obtained a series of certifications, including ISO9001, ISO14001, ISO56005, FDA, LFGB, NSF, RoHS, REACH, and more. Backed by a distinctive corporate culture, Skoocom brings together elite talents in management, R&D, and marketing. Infusing modern values with a relentless pursuit of innovation and self-transcendence, we are actively forging a next-generation modern enterprise defined by high-caliber talent, high-tech prowess, and high-growth potential. Thanks to our cutting-edge technologies, premium product lineup and comprehensive customer support, Skoocom's manufacturing facilities have hosted on-site inspections and guidance sessions led by senior officials from the Guangdong Provincial and Dongguan Municipal governments. The Skoocom brand has earned long-term partnerships and high acclaim from customers worldwide. Beyond consistently maintaining a leading market share, our products are highly favored in key international markets, including the United States, Germany, Japan, and South Korea.
Our Certificate




Frequently Asked Questions
1. Is SC1801PPV an air pump or a water pump?
It should be classified as a vacuum air pump because the supplied specification identifies the medium as air and provides airflow and vacuum data. A conflicting pump-body label should be corrected or explained before mass publication.
2. Can SC1801PPV pump cosmetic liquid or essence?
No liquid capability is established by the supplied specification. The listed medium is air. Use a liquid trap, filter and anti-backflow design to prevent moisture or cosmetic fluid from entering the pump.
3. Can the pump's −32kPa vacuum be applied directly to skin?
The pump-level vacuum is not a recommended skin-contact setting. The finished beauty device must establish its own safe operating range and use sensing, valves, software limits and release protection.
4. Does SC1801PPV support PWM speed control?
PWM capability should be confirmed for the selected motor version and driver. Do not assume support solely from generic product copy.
Request an SC1801PPV Engineering Sample
Send the target operating vacuum, airflow, cycle profile, voltage, acoustic target, tubing, valve restriction, moisture protection and annual demand for an application review.
