Shenzhen Skoocom Electronic Co.,Ltd is one of the leading manufacturers and suppliers of skoocom sc0520rvg dc mini solenoid valve in China. We provide high quality products for medical devices and beauty appliance. Welcome to wholesale CE approved and ISO certified products made in China here and get quotation from our factory. Also, custom service and ODM service are available.
| Structure | 2-position 3-way | |
| Mode | Normally closed | |
| Rated voltage | DC4.5V | DC5.0V |
| Rated current | 410mA | 371mA |
| Resistance | 11Ω±10% | 13.5Ω±10% |
| Pressure | -450mmHg | |
| Exhaust Time | 3.0 seconds from 300mmHg reduce to 15mmHg in 100CC tank. | |
| Leakage | 3mmHg/min from 300mmHg at 100CC tank. | |
| Insulation Level | A | |
| Medium | Air | |
| Lifetime test | 200.000 Times | |
| Working environment | 0～50 ℃,75% RH | |
