Shenzhen Skoocom Electronic Co.,Ltd is one of the leading manufacturers and suppliers of SC0526GL Miniature Air Solenoid Valve (DC 3-12V) in China. We provide high quality products for medical devices and beauty appliance. Welcome to wholesale RoHS, REACH and ISO certified products made in China here and get quotation from our factory. Also, custom service and ODM service are available.
SC0526GL Miniature Air Solenoid Valve
The SC0526GL is a compact 2-way normally open micro solenoid air valve designed for precision pressure control in portable and OEM medical devices. Operating efficiently across DC 3.0V, 6.0V, and 12.0V configurations, this valve delivers consistent airflow management in space-constrained hardware. Check the video for our air solenoid valve.
Products Specification
| Rated Voltage | DC 3.0V / 6.0V / 12.0V |
| Type | 2-Way / Normally Open |
| Exhaust Time | < 3.0s (300mmHg to 15mmHg at 100cc tank) |
| Leakage | < 3mmHg/min |
| Lifespan |
> 200,000 Times |
Application
For Medical Blood Pressure Monitors:
Accurate blood pressure readings depend on controlled, linear deflation. The SC0520GL features a rapid exhaust profile, reducing pressure from 300 mmHg down to 15 mmHg in under 3.0 seconds (tested in a 100cc tank). Its low leakage rate of less than 3 mmHg/min ensures stable pressure retention during inflation cycles, supporting strict measurement accuracy required for clinical and home-use sphygmomanometers.
For Wearable & Portable Massagers：
In pneumatic compression therapy and massage devices, rapid responsiveness and low energy usage directly impact battery efficiency and user experience. With operating currents as low as 45mA to 67mA depending on voltage, the SC0520GL minimizes power draw while delivering reliable air release. Its compact footprint (20*15.2*13 mm) allows easy integration into slim hand-held devices and wearable wraps without adding bulky weight.
About SKOOCOM
Twice-Recognized "Little Giant" Expertise
Awarded the national "Little Giant" title twice by MIIT (2022 and 2025), Skoocom brings over two decades of R&D expertise in precision micro pumps and valves for medical, smart home, and health application sectors.
End-to-End Vertical Manufacturing
Operating self-built 50,000 ㎡ facilities with dedicated subsidiaries for R&D, precision molding, rubber, and liquid silicone, we control every production stage to ensure consistent quality and scalable cost efficiency.
Proven High-Volume Output & Reliability
With an annual capacity of 50 million units, our products undergo rigorous testing and meet international standards-including ISO9001, ISO14001, FDA, LFGB, NSF, RoHS, and REACH-for reliable global distribution.
Trusted Global Industry Reputation
Serving key international markets across the US, Germany, Japan, and South Korea, Skoocom builds long-term OEM partnerships by delivering durable, low-noise, and low-power fluid control solutions.
Why choose SKOOCOM
Here Are Four Reasons Why You Should Choose Us
Rooted in Fluid Control, Forging National Intelligent Manufacturing.
Over more than two decades of exploration and development, Skoocom has established four subsidiaries, each responsible for one of four key sectors: Product R&D, Precision Molding, Precision Rubber, and Liquid Silicone Rubber. This not only creates economies of scale but also continuously strengthens the foundation for Skoocom's growth and expansion by reducing costs, improving service quality, and enhancing innovation capabilities.
Our Certificate
RoHS
ISO9001
REACH
ISO14001
Our factory
Patent
Comparison of product parameters
| Products name | 2-way valve | 3-way valve | 2-position 3-way valve |
| Products model | SC0526GC | SC0415GF | SC0726GF |
| Products material | ABS+Aluminum alloy | ABS+Alloy | ABS+stainless Iron |
| Rated voltage | 3v,4.5v,5v,6v,12v | 3v,4.5v,6v,12v | 6v,12v |
| Pressure | -450mmHg | 350mmHg | 350mmHg |
| Leakage | 3mmHg/min from -200mmHg at 100cC tank. | 3mmHg/min from 300mmHg at 100CC tank. | 3mmHg/min from 300mmHg at 100cC tank. |
| Lifetime test | 1, 000 times/500h (working 1.7s, off 0.8s working 30min, stopping 10min ) |
200.000 Times (12s on, 5s off) | 200.000 Times |
|
Working environment |
0~50 ℃, 75% RH | 0~50 ℃, 75% RH | 0~50 ℃, 75% RH |
Solenoid valve's abstract
Air Release valve. Air Release Valves, or Air Relief Valve function to release air pockets that collect at each high point of a full pressured pipeline. An air release valve can open against internal pressure, because the internal lever mechanism multiplies the float force to be greater than the internal pressure.
